Core: MDF
Slot Width: 6mm or 1/4"
Sloth Length: 56 mm or 2 3/16"
Center-to-Center Horizontal: 24mm or 15/16"
Center-to-Center Vertical: 96mm or 3 3/4"
Panel Thickness: 19mm or 3/4"
Edge Profile: Tongue and Groove or Square Edge
Available Sizes - Slotted Wood Panels (SL56)
| WIDTH |
LENGTH |
THICKNESS |
| 23-5/8" |
23-5/8" |
3/4" |
| 23-5/8" |
47-1/4" |
3/4" |
| 23-5/8" |
94-1/2" |
3/4" |
| 47-1/4" |
94-1/2" |
3/4" |
| *We offer custom sizing for all our panels, max length on Class A (Fire Rated) panels is 94-1/2". |
