Core: MDF
Hole Diameter: 3 mm or 1/8"
Center-to-Center Distance: 16mm or 5/8"
Panel Thickness: 19mm or 3/4"
Edge Profile: Tongue and Groove or Square
NRC Value: .65 Tested with 2" Fiberglass 3 pcf insulation (E-300 mounting)
.75 Tested with the 1" TerraCore Polyester
Available Sizes
| WIDTH |
LENGTH |
THICKNESS |
| 23-5/8" |
23-5/8" |
3/4" |
| 23-5/8" |
47-1/4" |
3/4" |
| 23-5/8" |
94-1/2" |
3/4" |
| 47-1/4" |
94-1/2" |
3/4" |
| *We offer custom sizing for all our panels, max length on Class A (Fire Rated) panels is 94-1/2". |
